High Precision And High Stability Tubular Sensor Medical Temperature Sensor Fast Response
NTC temperature sensor (temsensor) is the most common sensor in industrial production. It converts the temperature of the object into an electrical signal output. The NTC temperature sensor has the advantages of simple structure, wide measurement range, good stability and high precision. Different NTC temperature sensors are manufactured in different ways, and the common ones are thermistors, thermocouples and integrated products. Its development has generally gone through the stage from split type, analog integration to intelligent type.
NTC temperature sensor not only outputs temperature signal, but also integrates humidity measurement, and the signal output is also changed from the original single signal to a variety of output forms, which can carry out long-distance communication, data can be recorded according to needs, upper limit alarm and automatic control, etc. function.
NTC thermistor temperature sensor characteristics:
1. High precision and high stability
2. Fast response
3. Excellent thermal shock resistance
4. Excellent moisture resistance
5. High-tech batch production ensures high quality and high stability of products.
|
Type
|
NTC(thermistor) Temperature Sensor
|
|
Temperature range
|
-50℃ ~ +300℃；Customized
|
|
Accurancy
|
1%；5%；10%
|
|
RT(25℃)
|
1K；2K；2.2k；2.7k；3K；5K；7K；8K；12K；15K；20K；25K；30K；40K；47K；50K；60K；70K；100K；200K；230K；250K；470K；500K；1000K；Customized
|
|
B value
|
3274；3435；3470；3928；3950；3977；4100；4200；4400；Customized
|
|
Probe Material
|
Stainless steel SS304； aluminum；copper；plastic；epoxy；glass
|
|
Installation
|
Flanged；Surface；Threaded；Plastic；Straight；Film；Customized
|
|
Wire Material
|
Heat shrinkable tube；PVC tube；glass fiber tube； tube
|
|
Connector
|
Molex；JST；DuPont；CWB；CJT；U type；Customized
|
|
Waterproof
|
IP67；IP68
|
Main Technology Parameters
| Part number | Rated resistance R25 | B value (25/50) |
Dissipattion Coeffient.
|
Thermal time constant | Operating temperature | ||
| Range KOhm | Tolerance % | (K) | Tolerance % | Mw/℃ | sec | ℃ | |
| CWF□□□3100 | 0.1~20 |
±1 ±2 ±3 ±5 |
3100 | ±1 | ≥2.2 | ≤70 | -55~+125 |
| CWF□□□3270 | 0.2~20 | 3270 | |||||
| CWF□□□3380 | 0.5~50 | 3380 | |||||
| CWF□□□3470 | 0.5~50 | 3470 | |||||
| CWF□□□3600 | 1~100 | 3600 | |||||
| CWF□□□3950 | 5~100 | 3950 | |||||
| CWF□□□4000 | 5~100 | 4000 | |||||
| CWF□□□4050 | 5~200 | 4050 | |||||
| CWF□□□4150 | 10~250 | 4150 | |||||
| CWF□□□4300 | 20~1000 | 4300 | |||||
| CWF□□□4500 | 20~1000 | 4500 | |||||
NCT temperature sensor application range
◆Heating and heating air conditioners and related equipment
◆Household appliances of various sizes: air conditioners, refrigerators, battery stoves, bread ovens, baking ovens, electric ovens, microwave ovens, electric fans, soybean milk machines, electric water heaters, electric rice cookers, disinfection cabinets, water dispensers, heaters, electric irons, disinfection Cabinets, drinking fountains, lighting appliances, etc.
◆Temperature measurement and control circuits for agricultural, medical, environmental protection, meteorological, food processing and other equipment
◆Instrument coils, automotive circuits, integrated circuit modules, transistor amplifier circuits, temperature compensation circuits such as quartz crystal oscillators and thermocouples
Working principle of temperature sensor
Using the NTC thermistor under a certain measurement power, the resistance value drops rapidly as the temperature rises. Utilizing this feature, the NTC thermistor can be used to determine the corresponding temperature by measuring its resistance value, so as to achieve the purpose of detecting and controlling the temperature.
Conventional product electrical performance parameters
|
Part No.
|
R25℃
(KΩ)
|
B(K)
25/50℃
|
Rated Power @25℃(mW)
|
Dissipation Factor(δ)
(mW/℃)
|
Thermal time
Constant (S)
|
|
TS502□3274A
|
5.0
|
3274
|
10-20
|
2-4
|
5-20
|
|
TS502□3435B
|
5.0
|
3435
|
10-20
|
2-4
|
5-20
|
|
TS502□3470A
|
5.0
|
3470
|
10-20
|
2-4
|
5-20
|
|
TS502□3950A
|
5.0
|
3950
|
10-20
|
2-4
|
5-20
|
|
TS103□3274A
|
10.0
|
3274
|
10-20
|
2-4
|
5-20
|
|
TS103□3435B
|
10.0
|
3435
|
10-20
|
2-4
|
5-20
|
|
TS103□3470A
|
10.0
|
3470
|
10-20
|
2-4
|
5-20
|
|
TS103□3950A
|
10.0
|
3950
|
10-20
|
2-4
|
5-20
|
|
TS103□4100A
|
10.0
|
4100
|
10-20
|
2-4
|
5-20
|
|
TS153□3950A
|
15.0
|
3950
|
10-20
|
2-4
|
5-20
|
|
TS153□4100A
|
15.0
|
4100
|
10-20
|
2-4
|
5-20
|
|
TS203□3950A
|
20.0
|
3950
|
10-20
|
2-4
|
5-20
|
|
TS203□4100A
|
20.0
|
4100
|
10-20
|
2-4
|
5-20
|
|
TS223□4200A
|
22.0
|
4200
|
10-20
|
2-4
|
5-20
|
|
TS403□3928A
|
40.0
|
3928
|
10-20
|
2-4
|
5-20
|
|
TS503□3950A
|
50.0
|
3950
|
10-20
|
2-4
|
5-20
|
|
TS503□4100A
|
50.0
|
4100
|
10-20
|
2-4
|
5-20
|
|
TS104□3950A
|
100.0
|
3950
|
10-20
|
2-4
|
5-20
|
|
TS104□4100A
|
100.0
|
4100
|
10-20
|
2-4
|
5-20
|
|
TS104□4400A
|
100.0
|
4400
|
10-20
|
2-4
|
5-20
|
