Product Details:
|
| Size: | 0402-1206 | Thermal Time Constant: | <5S |
|---|---|---|---|
| Product: | SMD NTC Thermistor | Constant (25/50℃) （K）: | 3200/ 3380/ 3435/ 3600/ 3950/ 4100/ 4250/ 4500 |
| Dissipation Factor: | <=1.0mW/℃ | Nominal Zero-Power Resistance: | 4.7KΩ-150KΩ |
| Accuracy: | ±1%~±5% | Time Constant: | <=30S |
| Highlight: | 0603 series NTC thermistor,NTC 68Kohm thermistor |
||
Introduction of 0603 series NTC chip thermistor:
NTC thermistor is a kind of ceramic semiconductor thermosensitive crystal sintered from manganese, cobalt and nickel as raw materials. It is extremely sensitive to temperature changes. As the temperature increases, the resistance value decreases exponentially, and the temperature coefficient is as high as (3~6%/°C), and a small temperature change will cause a large change in the resistance value. According to the R-T resistance temperature curve of the thermistor, the precise resistance value of each temperature point can be measured and calculated. In the circuit, the digital correspondence of the temperature can be realized through the resistance value, which is used for temperature measurement and control.
0603 series NTC chip thermistor features:
1) Small size, no leads, excellent soldering performance, suitable for high-density surface mount;
2) The surface of the ceramic body is encapsulated by glass, which has good moisture resistance, high reliability and stability;
3) Wide working temperature range: -40℃~+125℃;
4) High precision resistance value and B value constant;
5) Comply with RoHS environmental protection standard
0603 series NTC chip thermistor application range:
Temperature measurement: electronic thermometer, electronic perpetual calendar, electronic clock temperature display, electronic gifts, etc.;
Temperature control: temperature sensing of rechargeable batteries in mobile phones, car phones, laptops, smart wearable devices, etc.;
Temperature Compensation: Temperature compensation of transistors, ICs and crystal oscillators in mobile communication devices.
SMD NTC Thermistor is a chip package thermistor, which is widely used in electronic industry. It is a kind of NTC chip thermistor with excellent performance. We offer SMD NTC Thermistor 0805(2012)wholesale sales. The accuracy of this product is within ±1%~±5%, and its permissible operating current is 0.31mA (25℃). The time constant is <=30S and its dissipation factor is <= 1.0mW/℃. The constant (25/50℃) (K) is 3200/ 3380/ 3435/ 3600/ 3950/ 4100/ 4250/ 4500. This SMD NTC Thermistor is an ideal choice for many applications.
| Parameters | Details |
|---|---|
| Product | SMD NTC Thermistor 0805(2012), SMD NTC Thermistor 0402(1005), High precision chip NTC thermistor |
| Permissible Operating Current (25℃) | 0.31mA |
| Constant (25/50℃)(K) | 3200/ 3380/ 3435/ 3600/ 3950/ 4100/ 4250/ 4500 |
| Size | 0402-1206 |
| Accuracy | ±1%~±5% |
| Thermal Time Constant | <5S |
| Rated Electric Power(25℃) | 100(mW) |
| Nominal Zero-Power Resistance | 4.7KΩ-150KΩ |
| Operating Temperature Range | -40℃~+125℃ |
| Dissipation Factor | <=1.0mW/℃ |
LINKUN's SMD NTC Thermistor is a factory direct sales product with 0603(1608) size and negative temperature coefficient thermistor. It has a thermal time constant of less than 5S, rated electric power of 100mW, and an accuracy of ±1%~±5%. It has UL, ROHS, and REACH certifications, with a minimum order quantity of 4000 Pieces. This product is suitable for operating within a temperature range of -40℃~+125℃, and comes with a tape packaging of 4000pcs/disk. The delivery time is 10 workdays, and the payment terms are T/T, Western Union, or MoneyGram. With a supply ability of 1000,000,000 Pieces per month, and a price to be determined, LINKUN's SMD NTC Thermistor is the perfect choice for your temperature sensing needs.
Brand Name: LINKUN
Model Number: 1608X103F3450FB
Place of Origin: Dongguan,Guangdong,China
Certification: UL,ROHS,REACH
Minimum Order Quantity: 4000 Pieces
Price: TBA
Packaging Details: Tape, 4000pcs/disk
Delivery Time: 10 workdays
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000,000,000 Pieces Per Month
Nominal Zero-Power Resistance: 4.7KΩ-150KΩ
Size: 0402-1206
Storage Temperature Range: -40℃~+125℃
Rated Electric Power(25℃): 100(mW)
Permissible Operating Current ( 25℃): 0.31mA
LINKUN is specialized in SMD negative temperature thermistor, Chip package thermistor, Chip package thermistor, NTC thermistor. Our thermistor has a nominal zero-power resistance ranging from 4.7KΩ-150KΩ, size from 0402-1206, and rated electric power of 100mW(25℃). It also has a storage temperature range of -40℃~+125℃ and a permissible operating current of 0.31mA(25℃). We provide UL, ROHS, and REACH certification, and have a minimum order quantity of 4000 pieces. Our delivery time is 10 workdays and we accept payment by T/T, Western Union, or MoneyGram. We supply up to 1000,000,000 pieces per month. Prices vary depending on the order size and requirements.
We provide technical support and service for SMD NTC Thermistor products, including:
Our technical support and service team is available to answer any questions you may have about our SMD NTC Thermistor products.
SMD NTC Thermistor will be packaged and shipped in a box with appropriate cushioning to ensure secure transport.
The box should be sealed with tape to protect the contents from any potential damage during shipping. The box should be clearly labeled with the product name, quantity, and other relevant shipping information.
The box should be placed on a pallet or in a container to ensure that it is not damaged during transit.
