Product Details:
|
| Material: | Silicon Single Crystal | Allowable Deviation: | ±0.5% |
|---|---|---|---|
| Product Name: | KTY84-152 | Cable:: | UL1332 26AWG TS Black PTFE |
| Terminal:: | 2.0 Copper Strip Terminal | Output Type Wire Type: | (three Cores) |
| Temperature Coefficient: | PTC | High Light:: | SiliconKTY81 KTY83 KTY84 PTC Thermistor, Copper Strip Linear Ptc Thermistor |
| Highlight: | Three Cores Silicon Thermistor,Single Crystal Silicon Thermistor |
||
PTFE coated silicon PTC thermistor temperature sensor KTY81 KTY83 KTY84 KTY10 620MM
Silicon Thermistor KTY84-152 Linear PTC Positive Temperature Cylindrical Silicon Single Crystal Thermistor
1. Description of silicon PTC thermistor temperature sensor
Silicon PTC thermistor temperature sensor KTY84-150-620TW is made of chip KTY84-150 and is compatible with KTY83-1KΩ series. The chip is soldered to the PTFE cable UL1332 26AWG TS Black through 2.0 copper bus terminals, and then encapsulated with 2.0 PTFE heat shrink tube for a compact design. It has the characteristics of fast response, long-term stability and good consistency. "Silicon material positive electrode" temperature coefficient "KTY series thermistor and temperature sensor" is suitable for "drive motors and control motors". The main models include KTY84-130, KTY84-150, KTY84-151 and KTY84-152. The sensor The lead length and color can be customized.
2.Typical Application Of The Silicon PTC Thermistor Temperature Sensor
Motion control temperature sensor, temperature sensing and controls in drives and motors, spindles, inverters and control systems, etc.
Industrial automation control equipment.
Home appliance temperature detection and compensation.
Precision circuit and crystal oscillator temperature compensation.
Temperature compensation of silicon semiconducting devices.
Temperature compensation of instrumentation amplifier.
A/D converter temperature compensation.
Micro motor timing control.
Automobile temperature detection and control.
Medical equipment temperature detection and control.
Linear PTC thermistors applications also include transmission, engine oil and coolant, heating system, overheating protection, amplifiers, power supplies, transducers, telemetry, computers, magnetic amplifiers, thermometry, meteorology, temperature regulation and over-temperature protection.
3. Dimension Of The Silicon PTC Thermistor Temperature Sensor (unit:mm)
| Serial number | Material name | Specifications / Models | Texture of material |
| 2-1. | LEAD WIRE | UL1332 26AWG TS Black(OD1.0±0.1mm) | PTFE |
| 2-2. | TERMINAL | 2.0 Copper strip terminal | |
| 2-3. | TUBE | 2.0 PTFE heat shrinkable tube | |
| 2-4. | THERMISTOR | R25=580Ω±40Ω | LK-KTY84-150 |
4. Specification Of The Silicon PTC Thermistor Temperature Sensor
| Serial number | Item | Test Conditions | Min. | Nor. | Max. | Unit |
| 3-1. | Resistance At 25℃ |
Ta=25±0.05℃ PT≦0.1mw |
540 | 580 | 620 | Ω |
| 3-2. | Resistance At 100℃ |
Ta=100±1℃ PT≦0.1mw |
950 | 1000 | 1050 | Ω |
| 3-3. | Insulation test | 100VDC | 100 | / | / | MΩ |
| 3-4. | Withstand voltage test |
1250V AC 2mA In still air |
5 | / | / | Sec |
| 3-5. | Operation Temperature Range | / | -40 | / | +150 | ℃ |
| 3-6. | Rated Current IN | / | / | 2 | / | mA |
| 3-7. | Max Current Imax | / | 8 | mA | ||
| 3-8. | Thermal Time τ | In still air | / | / | 7 | S |
| 3-9. | Dissipation factor δ | In still air | 1.5 | / | / | mW/℃ |
| 3-10. | Rated Power Pmax | / | / | / | 50 | mW |
5. R-T Characteristic Parameter Table Of The Silicon PTC Thermistor Temperature Sensor
| Celsius | Fahrenheit | LK-KTY84-150 | ||||
| ℃ | ℉ | %/(K) | (Ω) | (K) | ||
| MIN | TYP | MAX | ||||
| -40 | -40 | 0.97 | 294 | 322 | 350 | ±8.85 |
| -30 | -22 | 0.94 | 327 | 356 | 385 | ±8.76 |
| -20 | -4 | 0.91 | 361 | 392 | 423 | ±8.7 |
| -10 | 14 | 0.88 | 397 | 430 | 463 | ±8.65 |
| 0 | 32 | 0.87 | 434 | 469 | 504 | ±8.61 |
| 10 | 50 | 0.85 | 475 | 512 | 549 | ±8.58 |
| 20 | 68 | 0.82 | 517 | 556 | 595 | ±8.55 |
| 25 | 77 | 0.80 | 540 | 580 | 620 | ±8.54 |
| 30 | 86 | 0.79 | 562 | 603 | 644 | ±8.53 |
| 40 | 104 | 0.78 | 610 | 653 | 696 | ±8.5 |
| 50 | 122 | 0.75 | 659 | 704 | 749 | ±8.46 |
| 60 | 140 | 0.73 | 711 | 758 | 805 | ±8.42 |
| 70 | 158 | 0.67 | 768 | 814 | 860 | ±8.37 |
| 80 | 176 | 0.63 | 827 | 873 | 919 | ±8.31 |
| 90 | 194 | 0.62 | 887 | 935 | 983 | ±8.25 |
| 100 | 212 | 0.62 | 950 | 1000 | 1050 | ±8.17 |
| 110 | 230 | 0.62 | 1011 | 1068 | 1125 | ±8.66 |
| 120 | 248 | 0.58 | 1077 | 1138 | 1199 | ±9.17 |
| 130 | 266 | 0.52 | 1148 | 1209 | 1270 | ±9.69 |
| 140 | 284 | 0.51 | 1215 | 1282 | 1349 | ±10.24 |
| 150 | 302 | 0.50 | 1279 | 1352 | 1425 | ±10.8 |
6. Features Of The Silicon PTC Thermistor Temperature Sensor
1. KTY84 temperature sensor chip, the structure is based on the principle of diffusion resistance, with a true approximate linear temperature coefficient, ensuring high accuracy of temperature measurement. (The temperature changes from -40°C to +180°C, and the resistance value changes approximately linearly from about 300Ω to 1600Ω.)
2. KTY84 temperature sensor chip, based on "silicon batch processing technology", has good product consistency and strong interchangeability."
3. KTY84 temperature sensor chip, the main component is silicon, silicon is inherently stable, so it has extremely high reliability and extremely long service life (it has very little drift in up to 50 years, repeating its characteristics for millions of times The curve remains unchanged.)
4. KTY84 temperature sensor chip, the electrode is a Ni-Sn composite electrode, which has high reliability and good solderability.
5. KTY84 standard components are DO-35 glass packaging structure with axial leads. The structure is firm, the electrode contact is stable, and it can be used in harsh environments such as high temperature, high humidity and extreme cold. The appearance is standardized, and it has a small size and fast response. advantage.
6. The KTY84 temperature sensor is packaged and connected with PTFE leads and heat shrinkable tubes, and can withstand temperatures above 200°C. The resistance and leads are connected by copper tape riveting.
7.Silicon Sensors Application Precaution Of The Silicon PTC Thermistor Temperature Sensor
Minimum lead wire length tailored to shall be ≥8mm.
In lead wire bending, bending point shall be more than 2mm away from glass body part.
8.Mounting and Handling Recommendations
Excessive forces applied to a sensor may cause serious damage. To avoid this, the following recommendations should be adhered to:
No perpendicular forces must be applied to the body
During bending, the leads must be supported
Bending close to the body must be done very carefully
Axial forces to the body can influence the accuracy of the sensor and should be avoided
These sensors can be mounted on a minimum pitch of >5 mm
9.Soldering and Welding
Avoid any force on the body or leads during, or just after, soldering.
Do not correct the position of an already soldered sensor by pushing, pulling or twisting the body.
Prevent fast cooling after soldering.
For hand soldering, where mounting is not on a printed-circuit board, the soldering temperature should be <300C the soldering time <3 s and the distance between body and soldering point >1.5 mm.
For hand soldering, dip, wave or other bath soldering, mounted on a printed-circuit board, the
soldering temperature should be <300C, the soldering time <5 s and the distance between body and soldering point >1.5 mm.
The distance between the body and the welding point should be >0.5 mm. Care should be taken to ensure that welding current never passes through the sensor.
﹡KTY types and LPTC types are all DO-35 precision glass sealed
﹡Our company undertakes the production of various sensors using the above components
﹡To facilitate installation, our company can undertake products of the same type and specifications with one-way lead plastic packaging components
﹡The company's research, development and production of silicon thermistors and sensors with various special parameters and structural forms
Different wire lengths can be customized, and the following specifications can be processed:
Model: KTY83-110 KTY83-120 KTY83-121 KTY83-122 KTY83-150 KTY83-151 KTY83-152
KTY83-110 R25℃=1000Ω ±1% operating temperature -40℃~175℃
KTY83-120 R25℃=1000Ω ±2% operating temperature -40℃~175℃
KTY83-121 R25℃=990Ω ±1% operating temperature -40℃~175℃
KTY83-122 R25℃=1010Ω ±1% operating temperature -40℃~175℃
KTY83-150 R25℃=1000Ω ±5% operating temperature -40℃~175℃
KTY83-151 R25℃=975Ω ±2.5% Working temperature -40℃~175℃
KTY83-152 R25℃=1025Ω ±2.5% Working temperature -40℃~175℃
Factory real shot display:
Product Description:Product Overview - PTC ThermistorWelcome to our brand new Silicon PTC Thermistor Temperature Sensor, the perfect solution for your temperature sensing needs. This product is designed and manufactured to provide accurate and reliable temperature measurements in a variety of applications.
Our PTC Thermistor features a tube length of 50mm, providing a compact and space-saving design for easy installation in any system. This length is ideal for a wide range of applications, including industrial, medical, and consumer electronics.
The output type for our PTC Thermistor is wire type, specifically three cores. This allows for easy integration into any existing wiring system, providing a seamless and hassle-free installation process.
Our PTC Thermistor is made with high-quality materials, including silicon KTY81 and copper strip. These materials are known for their durability, accuracy, and reliability, making our PTC Thermistor a top choice for temperature sensing applications.
The cable used for our PTC Thermistor is UL1332 26AWG TS Black PTFE, known for its excellent insulation and heat resistance properties. This ensures safe and reliable operation of the PTC Thermistor in a wide range of temperature conditions.
Our PTC Thermistor is a positive temperature coefficient thermistor, meaning its resistance increases with an increase in temperature. This makes it an ideal choice for temperature control and protection applications, providing accurate and precise temperature measurements.
In conclusion, our Silicon PTC Thermistor Temperature Sensor is a high-quality, reliable, and accurate solution for all your temperature sensing needs. Its compact design, versatile output type, and use of top-quality materials make it a top choice for a wide range of applications. Choose our PTC Thermistor and experience the best in temperature sensing technology.
| Product Name | Silicon PTC Thermistor Temperature Sensor |
|---|---|
| Tube Length | 50mm |
| High Light | Silicon KTY81 PTC Thermistor, Copper Strip Linear Ptc Thermistor |
| Cable | UL1332 26AWG TS Black PTFE |
| Cable Length | 620mm |
| Resistance | R25=580Ω±40Ω |
| Tube | 2.0 PTFE Heat Shrinkable Tube |
| Sensing Thermistor | LK-KTY84-150 |
| Output Type Wire Type | Three Cores |
| Terminal | 2.0 Copper Strip Terminal |
Brand Name: Lin Kun
Model Number: Silicon PTC Thermistor Temperature Sensor
Place of Origin: China
Terminal: 2.0 Copper Strip Terminal
Tube Length: 50mm
High Light: Silicon KTY81 PTC Thermistor, Copper Strip Linear Ptc Thermistor
Resistance: R25=580Ω±40Ω
Sensing Thermistor: LK-KTY84-150
The Positive Temperature Coefficient (PTC) Thermistor is a type of thermistor that exhibits a positive resistance-temperature relationship. This means that as the temperature increases, the resistance of the thermistor also increases. This unique property makes PTC thermistors useful in a variety of applications.
PTC thermistors are widely used in temperature sensing and control applications. They are commonly used in household appliances such as refrigerators, air conditioners, and water heaters to accurately monitor and regulate temperatures. PTC thermistors are also used in automotive applications, such as temperature control in engine and cabin heating systems.
One of the key applications of PTC thermistors is as inrush current limiters. When an electronic device is turned on, it can draw a large amount of current in the initial seconds. PTC thermistors can be used to limit this inrush current and protect the device from damage. This makes them essential in power supplies, transformers, and other electronic devices.
Another important application of PTC thermistors is as temperature sensors in medical equipment. They are used in devices such as fever thermometers to accurately measure body temperature. PTC thermistors are also used in industrial equipment for temperature sensing and control in processes such as plastic molding and welding.
Imagine a hot summer day and you step into your air-conditioned home. The temperature is set to a comfortable level, thanks to the PTC thermistor in the air conditioner that accurately senses and maintains the desired temperature. As you pour yourself a cold drink from the refrigerator, the PTC thermistor in it ensures that your food and drinks are stored at the perfect temperature. In the evening, you hop into your car and turn on the air conditioning, which is also controlled by a PTC thermistor. As you drive, the engine temperature is constantly monitored by a PTC thermistor, ensuring that it doesn't overheat. When you reach your destination, you use a fever thermometer to check your child's temperature, relying on the accuracy of the PTC thermistor inside it. These are just some of the many scenes where PTC thermistors play a crucial role in our daily lives.
In conclusion, the Lin Kun Silicon PTC Thermistor Temperature Sensor is a high-quality product from China that can be used in various applications such as temperature sensing, control, and inrush current limiting. With its positive temperature coefficient and accurate resistance values, it is a reliable and efficient choice for any temperature-related needs.
Brand Name: Lin Kun
Model Number: Silicon PTC Thermistor Temperature Sensor
Place of Origin: China
Tube Length: 50mm
Output Type: Wire Type (Three Cores)
Tube: 2.0 PTFE Heat Shrinkable Tube
Cable Length: 620mm
Introducing our customized service for the Lin Kun Silicon PTC Thermistor Temperature Sensor. As a leading manufacturer and supplier of Positive Temperature Coefficient Thermistors, we are proud to offer our customers with customizable options to meet their specific needs and requirements.
With our Brand Name Lin Kun, you can trust the quality and reliability of our products. Our Model Number Silicon PTC Thermistor Temperature Sensor is designed to accurately measure and monitor temperature in various applications.
Made in China, our products adhere to strict quality standards and are manufactured using the finest materials. The Tube Length of our PTC Thermistor is 50mm, and it comes with an Output Type of Wire Type (Three Cores) for easy installation and use.
To ensure durability and protection, our PTC Thermistor is encased in a 2.0 PTFE Heat Shrinkable Tube. And with a Cable Length of 620mm, our product offers flexibility in its placement and usage.
Choose our Customized Service for your Silicon PTC Thermistor Temperature Sensor needs and experience the precision and accuracy of our products. Trust Lin Kun for all your Positive Temperature Coefficient Thermistor requirements. Contact us now to learn more.
Our PTC Thermistors are packaged in a sturdy and protective material to ensure safe delivery. Each thermistor is placed in a plastic or foam tray and then sealed in a polybag to prevent any damage during transportation.
For larger orders, the thermistors are packaged in a sturdy cardboard box with proper cushioning and placed in a pallet for added protection.
We offer various shipping methods to ensure timely delivery of our PTC Thermistors to our customers. These include:
For all orders, we provide a tracking number so customers can track the status of their shipment. We also ensure that all necessary customs documents are included to avoid any delays or issues during international shipping.
Our shipping charges are calculated based on the weight and destination of the order. Customers can choose their preferred shipping method and see the estimated shipping cost at the checkout page.
For any queries or concerns regarding packaging and shipping of our PTC Thermistors, please contact our customer support team for assistance.
