MZ4 Series PTC Heating Thermistor 16x5x2.5mm 36V 235C for Automotive Appliances

Large Image : MZ4 Series PTC Heating Thermistor 16x5x2.5mm 36V 235C for Automotive Appliances

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Linkun
Model Number:	MZ4 Heating PTC Thermistor
Document:	Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity:	5000
Price:	$0.38-0.42

Contact Now

MZ4 Series PTC Heating Thermistor 16x5x2.5mm 36V 235C for Automotive Appliances

Description

Dimensions:	1652.5mm	Voltage:	36V
Surface Temperature:	235C	Resistance:	20-50 Ohm
Resistance Tolerance:	±20% ±25% ±30% 50%	Material:	Ceramic Composition
Electrode Material:	Silver Electrode/aluminum Electrode	Shape:	Round
Operating Voltage Range:	1.5-68V	Surface Temperature Range:	35-350℃
Maximum Voltage:	36V	Curie Temperature:	235C
Function:	Temperature Regulation	Power Consumption:	3.2W
Maximum Current:	12A
Highlight:	PTC heating thermistor for automotive , MZ4 series PTC heating chip , 36V PTC thermistor with warranty

MZ4 Series Circular Heating PTC Thermistor

16×5×2.5mm 36V 235°C 20-50 ohm for small appliances and car heating

Product Specifications

Attribute	Value
Specification	16×5×2.5mm 36V 235°C 20-50 ohm
Packaging Type	Vacuum blister + carton
Application	Automobile industry/household appliance industry
Package/Case	Ceramic Composition
Series	MZ4 Heating PTC Thermistor
Features	Round piece
Size/Dimension	Customized Heater Element
Resistance	20-50 ohm
Resistance Tolerance	±20% ±25% ±30% 50%
Shape	Round
Function	Temperature regulation and automatic control function
Material	Ceramic Composition/Silver electrode/aluminum electrode

PTC Thermistor for Heating

Applications

Automotive Industry: Cabin heating, diesel preheating, windshield washer nozzles, battery pack temperature control
Household Industry: Washing machine door locks, warm air heating, medical equipment, fuel burner preheating
Other Applications: Fiber optic communication, camera lenses, plastic welding equipment

Key Features

Excellent lifespan characteristics
Built-in temperature regulation and self-control functions
Compact and lightweight design for easy installation
No fire risk during operation
Available in low voltage (1.5-68V) and high voltage (100-1000V) variants

Technical Parameters

Low Voltage Models

Product No.	Curie Temp (°C)	Surface Temp (°C)	25°C Resistor (Ω)	Operating Voltage (V)	Max Voltage (V)	Size (mm)

High Voltage Models

Product No.	Curie Temp (°C)	Surface Temp (°C)	25°C Resistor (Ω)	Operating Voltage (V)	Max Voltage (V)	Size (mm)

Note: □ represents the deviation range of R25 (M: ±20%, X: ±25%, N: ±30%, S: Special).
Operating voltage and surface temperature can be customized. Other specifications available upon request.

PTC Thermistor for Motor Starting

Chip Type (MZ9 Series)

Applications

Compressor starting for refrigerators and air conditioners
Single-phase induction motor starting
Inrush current suppression in power supplies and controllers

Features

Reliable metal electrode construction
Pressure clamping installation for long life
No electrical noise
High voltage and impact current resistance
Safety approvals: UL&CUL, VDE, CQC
RoHS compliant
